Description
Wisdom Cordless Lamp Charging Rack NWCR-24B
The NWCR-24/B is a double sided charger rack with 24 charging ports, 12 per side. Each lamp charges independently with an LED per charge port to indicate charging or fully charged.
Faster charging –
After applying intelligent fast-charging technology, the time required to charge the lamp fully is much less than before. For WISDOM Lamp 3D, it takes only 3 hours to get a full charge, while for Lamp 3A, about 5 hours is enough.
Higher efficiency, less heat –
Compared with the past generations of the chargers, the charger PCB of NWCR-12B is improved to be more efficient. Even when charged at full power, it generates only a little heat.
Wide range voltage –
The voltage range of the AC power supply is: 100~240V
The wide range makes the charger applicable to the specific voltage standard in all countries.
Environmentally-friendly –
The charging rack is designed under the Restriction of Hazardous Substances Directive (RoHS). RoHS standard is strictly followed in the whole process, from choosing the material to designing the production technique.
Technical specifications –
| Features | NWCR-24B Specifications |
|---|---|
| AC input | 100~240 V ± 10%, 5.4 A, 50~60 Hz |
| DC output voltage | 4.80 V/6.8V |
| DC output current | 2000 mA |
| Size | 65 × 30 × 106 cm; 25.6 x 11.8 x 41.7 in |
| Weight | 45 kg; 99.21 lb |
| Model | WISE LITE2(4.8V),WISDOM LAMP3/4(4.8V),WISDOM LAMP6(6.8V) |
